What is an air conditioner, and Parts of an Air Conditioner (eng) // Qué es un aire acondicionado, y partes de un aire acondicionado (Esp)

avatar
(Edited)

A cordial greeting to all the brothers of this beautiful of hive platform. This time I will talk a little of what is a split type air conditioner and what are some of its parts.

Portada ingles.png

There are several types of air conditioners, and this time we will begin by explaining a little what is a split type air conditioner: This split type air conditioner has 2 separate units, the indoor unit or console and the outdoor unit or condensing unit.

Foto 1 ingles.png

  • The internal unit or console, is responsible for extracting the hot air and transferring its heat to the refrigerant gas that passes through tubes to create condensation and cold air, all this with the help of a turbine or fan, this at the same time is also responsible for distributing the cooled air within the environment where the console or internal unit is located, this is called the refrigeration cycle.

  • The external unit or condensing unit, houses the condenser and compressor where the refrigerant gas changes from gas to liquid. From this unit the hot air is expelled to the outside (the heat that we have "removed" from the inside).

Let's talk a little and go explaining some parts of the split type air conditioner.

Foto 2 ingles.png

  • Display or thermostat: this is responsible for receiving the signal from the remote control and indicate the temperature that is requested, in some cases or depending on the brand and model, also indicates the temperature at which the environment is. also regulates the operation of the equipment as this together with the temperature sensors (room and well), once it has matched the room temperature with the temperature that has been requested to the equipment, they send the signal to the card to send to turn off the external unit or condenser.

Foto 3 ingles.png

  • The turbine or fan of the console: is an elongated piece located at the bottom inside that goes almost from one end to the other, is connected at one end to a motor that makes it work. The turbine is the one that circulates the air through the honeycomb or evaporator coil and in turn distribute the cold air. It is one of the pieces that has the air that is of utmost care as this has an almost perfect balance and even staples are placed at certain points to create that balance. If the turbine were to lose this balance either by rupture or even by the same accumulation of dirt that sticks in each of its fins, this vibrates a lot and comes to create a mismatch in the equipment and in the engine that moves it.

Foto 4 ingles.png

  • Drain pan: is responsible for collecting all the water produced by the evaporator or coil of the console and in turn drain that water, this tray must be placed completely level, since its design is structured to give the fall to the water collected to the drain point that is located in one of the lower corners of it. At the bottom of the tray, there are flaps and movable windows that are also driven by a small motor. The function of these is to direct the cold air expelled by the turbine, either from one side to the other, or from top to bottom, these are adjustable according to the taste of the person.

Foto 5 ingles.png

  • The card: talk and explain this card is very interesting, because it is the brain operator of all the equipment completely, like the human brain that is responsible for sending all the signals for each of the body parts, similarly carries the air card that sends all the signals for the perfect functioning of the equipment. Physically we can see that it is full of electronic components (diodes, capacitors and transformers) also connect the terminals of our main components such as: compressor, motors, various types of sensors, among others.

Foto 6 ingles.png

  • The condensing unit or external unit, unlike what I explained at the beginning of the post, this is composed of the compressor, the fan motor, capacitors and electrical part. I will explain the parts of this unit...

Foto 7 ingles.png

  • Capacitors and electrical part: In the electrical part arrives the cable that comes from the console with the signal (current) for the operation and start of this unit, from there the current is distributed to the compressor, fan motor and capacitors.
    Among the capacitors there are 2, the running capacitor and the fan motor capacitor.
  • Run capacitor: This is like a battery and is responsible for giving an impulse or force to the compressor to start, depending on the size or strength of the compressor this can be of greater capacity.
  • Fan motor capacitor: Like the run capacitor this is also like the battery and the one that gives the impulse but to the fan motor to start it, and also depending on the size and strength of the motor, the capacitor can be of greater capacity.

Foto 8 ingles.png

  • The compressor: As its name suggests its main function is to compress the refrigerant gas that allows, in a process of compression / decompression, produce a heat transfer from one part to another this is called '' refrigerant circuit ''. As in the card I made the comparison with the human body, in this case, the compressor would be like the heart, but this pumps the air in hot form, through an extensive copper pipe so that in the path that hot gas is cooling. The compressor generates a force that compresses the gas arriving from the evaporator or coil in gaseous state. This pressure increases the temperature of the gas, which causes it to return to its liquid state.

  • Fan motor: The job of this fan is to remove as much of the heat produced by the compressor into the condensing unit or outdoor unit. As the compressor generates so much hot air the fan motor is responsible for removing all that heat for the best performance of the compressor and thus avoid overheating of the same, also cooling the hot air passing through all the copper pipe that is inside the coil of the condensing unit.

This post I did it in order that many learned what is a split type air conditioner, what are its parts and explain what is the function of each of them.
In some ways it is my work and my day to day and I wanted to share it with you all, I hope you like it and is to your liking give me your support to continue making more post like this that is useful for everyone thank you very much and I hope you vote for me.

For the cover photo I used 2 images that were taken from Pixabay.com
https://pixabay.com/es/illustrations/acondicionador-de-aire-ac-fresco-4204637/
https://pixabay.com/es/photos/aire-acondicionado-ventilaci%C3%B3n-233953/
and edited on canva.com
The photos used in this post belong to me @marvin16 and were taken from my Samsung J2 cell phone and edited in canva.com.
This post was translated with the help of Deepl translator.


Agregar un subtítulo.png

Español

Un cordial saludo a todos los hermanos de esta hermosa plataforma de Hive. En esta ocasión voy a hablar un poco de lo que es un aire acondicionado tipo split y cuáles son algunas de sus partes.


Existen varios tipos de aires acondicionados, y en esta ocasión comenzaremos explicando un poco lo que es un aire acondicionado tipo split: Este aire acondicionado tipo split tiene 2 unidades separadas, la unidad interior o consola y la unidad exterior o unidad condensadora.

fOTO 1.png

  • La unidad interna o consola, se encarga de extraer el aire caliente y transferir su calor al gas refrigerante que pasa a través de tubos para crear la condensación y el aire frío, todo esto con la ayuda de una turbina o ventilador, este a su vez también se encarga de distribuir el aire frío dentro del ambiente donde se encuentra la consola o unidad interna, a esto se le llama ciclo de refrigeración.

  • La unidad externa o unidad condensadora, alberga el condensador y el compresor donde el gas refrigerante pasa de gas a líquido. Desde esta unidad se expulsa el aire caliente al exterior (el calor que hemos "quitado" del interior).

Vamos a hablar un poco e ir explicando algunas partes del aire acondicionado tipo split.

Foto 2.png

  • Display o termostato: es el encargado de recibir la señal del control remoto e indicar la temperatura que se solicita, en algunos casos o dependiendo de la marca y el modelo, también indica la temperatura a la que se encuentra el ambiente. también regula el funcionamiento del equipo ya que este junto con los sensores de temperatura (ambiente y del pozo), una vez que ha igualado la temperatura del ambiente con la temperatura que se ha solicitado al equipo, envían la señal a la tarjeta para que mande a apagar la unidad externa o condensador.

Foto 3.png

  • La turbina o ventilador de la consola: es una pieza alargada situada en la parte inferior interior que va casi de un extremo a otro, está conectada en un extremo a un motor que la hace funcionar. La turbina es la que hace circular el aire por el panal o serpentín del evaporador y a su vez distribuye el aire frío. Es una de las piezas que tiene el aire que es de sumo cuidado ya que este tiene un equilibrio casi perfecto e incluso se colocan grapas en ciertos puntos para crear ese equilibrio. Si la turbina perdiera este equilibrio ya sea por ruptura o incluso por la misma acumulación de suciedad que se pega en cada una de sus aletas, esta vibra mucho y llega a crear un desajuste en el equipo y en el motor que lo mueve.

Foto 4.png

  • Bandeja de desagüe: es la encargada de recoger toda el agua producida por el evaporador o serpentín de la consola y a su vez drenar esa agua, esta bandeja debe colocarse totalmente nivelada, ya que su diseño está estructurado para dar la caída al agua recogida hasta el punto de drenaje que se encuentra en una de las esquinas inferiores de la misma. En la parte inferior de la bandeja hay unas aletas y ventanas móviles que también son accionadas por un pequeño motor. La función de éstas es dirigir el aire frío que expulsa la turbina, ya sea de un lado a otro, o de arriba hacia abajo, éstas son ajustables según el gusto de la persona.

Foto 5.png

  • La tarjeta: hablar y explicar esta tarjeta es muy interesante, porque es el cerebro operador de todo el equipo por completo, como el cerebro humano que se encarga de enviar todas las señales para cada una de las partes del cuerpo, de manera similar lleva la tarjeta de aire que envía todas las señales para el perfecto funcionamiento del equipo. Físicamente podemos ver que está lleno de componentes electrónicos (diodos, capacitores y transformadores) también se conectan los terminales de nuestros principales componentes como: compresor, motores, varios tipos de sensores, entre otros.

Foto 6.png

  • La unidad condensadora o unidad externa, a diferencia de lo que he explicado al principio del post, esta se compone del compresor, el motor del ventilador, los capacitores y la parte eléctrica.
    Voy a explicar las partes de esta unidad...

Foto 7.png

  • Capacitores y parte eléctrica: En la parte eléctrica llega el cable que viene de la consola con la señal (corriente) para el funcionamiento y arranque de esta unidad, de ahí la corriente se distribuye al compresor, motor del ventilador y capacitores.
    Entre los capacitores hay 2, el capacitor de marcha y el capacitor del motor del ventilador.
  • Capacitor de marcha: Es como una batería y se encarga de dar un impulso o fuerza al compresor para arrancar, dependiendo del tamaño o fuerza del compresor este puede ser de mayor capacidad.
  • Capacitor del motor ventilador: Al igual que el capacitor de marcha este también es como la batería y el que da el impulso pero al motor del ventilador para arrancarlo, y también dependiendo del tamaño y fuerza del motor, el capacitor puede ser de mayor capacidad.

Foto 8.png

  • El compresor: Como su nombre indica su función principal es la de comprimir el gas refrigerante que permite, en un proceso de compresión/descompresión, producir una transferencia de calor de una parte a otra a esto se le llama ''circuito frigorífico''. Como en la tarjeta hice la comparación con el cuerpo humano, en este caso, el compresor sería como el corazón, pero este bombea el aire en forma caliente, a través de una extensa tubería de cobre para que en el trayecto ese gas caliente se enfríe. El compresor genera una fuerza que comprime el gas que llega del evaporador o serpentín en estado gaseoso. Esta presión aumenta la temperatura del gas, lo que hace que vuelva a su estado líquido.

  • Motor del ventilador_: La función de este ventilador es eliminar la mayor cantidad de calor producido por el compresor hacia la unidad condensadora o unidad externa. Como el compresor genera tanto aire caliente el motor del ventilador se encarga de eliminar todo ese calor para el mejor funcionamiento del compresor y así evitar el sobrecalentamiento del mismo, además de enfriar el aire caliente que pasa por toda la tubería de cobre que está dentro del serpentín de la unidad condensadora.

Este post lo realice con la finalidad de que muchos aprendieran que es un aire acondicionado tipo split, de cuales son sus partes y explicarles cual es la función de cada una de ellas.
En cierta forma es mi trabajo y es mi día a día y quise compartirlo con todos ustedes, espero les guste y sea de su agrado denme su apoyo para poder seguir realizando mas post como este que sea de utilidad para todos muchas gracias y espero me voten.

Para la foto de la portada he utilizado dos imágenes tomadas de Pixabay.com
https://pixabay.com/es/illustrations/acondicionador-de-aire-ac-fresco-4204637/
https://pixabay.com/es/photos/aire-acondicionado-ventilaci%C3%B3n-233953/
Editadas en canva.com
Las fotos utilizadas en este post me pertenecen @marvin16 y fueron tomadas desde mi celular Samsung J2 y editadas en canva.com.
Este post fue traducido con la ayuda del traductor Deepl.
Para más información: https://como-funciona.co/un-aire-acondicionado/
